Product Details: REF192ESZ Precision Voltage Reference

Introduction: The REF192ESZ is a high-precision voltage reference designed to meet the demanding requirements of precision analog applications. It is a low-dropout, low-noise voltage reference that provides a stable and accurate voltage output, making it ideal for various electronic systems.

Key Features:

1. High Precision: The REF192ESZ offers exceptional voltage accuracy, making it suitable for precision instrumentation and measurement equipment.
2. Low Dropout Voltage: With a low dropout voltage, this voltage reference maintains a stable output even when the input voltage is close to the output voltage.
3. Low Noise: Minimized output noise ensures clean and reliable voltage references, improving signal integrity.
4. Wide Temperature Range: Operates reliably across a broad temperature range, making it suitable for extreme environments.
5. Small Package: The REF192ESZ is available in a compact and space-saving package, enhancing its versatility in various applications.

Specifications:

• Voltage Output: 2.5V
• Output Voltage Tolerance: ±0.05%
• Temperature Coefficient: 5ppm/°C (typical)
• Input Voltage Range: 2.7V to 30V
• Dropout Voltage: 200mV (typical)
• Output Noise: 2μV p-p (0.1Hz to 10Hz)
• Operating Temperature Range: -40°C to 125°C

Applications:

1. Precision Measurement Equipment: The REF192ESZ is perfect for applications requiring high-precision voltage references, such as digital multimeters and oscilloscopes.

2. Data Acquisition Systems: Ensure accurate data conversion in ADCs with this voltage reference, enhancing the overall performance of data acquisition systems.

3. Analog Signal Conditioning: Use the REF192ESZ to improve the accuracy and stability of analog signal conditioning circuits.

4. Industrial Control Systems: Maintain precise control in industrial automation and control systems.

5. Aerospace and Defense: The wide temperature range makes it suitable for use in aerospace and defense applications.

Benefits:

• Improved Measurement Accuracy: The REF192ESZ helps in achieving accurate and reliable measurement results in your applications.
• Reduced Signal Distortion: Low output noise ensures that your analog signals remain clean and distortion-free.
• Robust and Versatile: This voltage reference is designed to withstand challenging conditions, making it suitable for various industries.
• Space-Saving: The compact package allows for easy integration into your PCB layout.

Pin Configuration: The REF192ESZ is available in a standard 8-pin SOIC package, making it easy to incorporate into your circuit design. The pin configuration is as follows:

1. Output
2. GND
3. GND
4. N/C (No Connection)
5. N/C (No Connection)
6. GND
7. N/C (No Connection)
8. Input

Typical Connection: To use the REF192ESZ in your circuit, connect the input (Pin 8) to your input voltage source, the GND pins (Pins 2, 3, 6) to ground, and the output (Pin 1) to your load or reference point.

Recommended Operating Conditions:

• Input voltage should be within the range of 2.7V to 30V.
• Operating temperature should be between -40°C and 125°C for best performance.

Ordering Information: When ordering the REF192ESZ, please specify the package type and quantity required. You can find the part number and package details in the datasheet provided by the manufacturer.

Conclusion: The REF192ESZ precision voltage reference is a reliable and accurate solution for applications demanding high precision and low noise. Its wide operating temperature range, low dropout voltage, and small form factor make it an excellent choice for precision analog circuits in various industries, ensuring accurate and stable voltage references for your critical designs.
